General data Model Pure Wings 2 140mm high-speed Dimensions (mm) 140 Color option Black Lighting – Fan speed at 100% PWM / 12V (rpm) 1600 Noise level at 100% PWM / 12V (dB(A)) 36.3 Airflow at 100% PWM / 12V (CFM / m3/h) 94.2 / 160 Air Pressure at 100% PWM / 12V (mm H2O) 1.82 Mechanical specifications Dimensions (L x W x H), (mm) 140 x 25 x 140 Weight incl. fixed cables (g) 158 Bearing technology Rifle Motor technology 4-pole fan motor Push pin fixing – Screw fixing ✓ Cables / Connectors Daisy-chain compatible – Lighting connector – Connector 3-pin Cable length (mm) 460 Cable sleeve – Performance / Noise Airflow at 100% PWM / 12V (CFM / m3/h) 94.2 / 160 Air Pressure at 100% PWM / 12V (mm H2O) 1.82 Noise level at 100% PWM / 12V (dB(A)) 36.3 Lifespan (h / 25°C) 80,000 Zero RPM mode – Electrical specifications Rated Voltage DC (V) 12 Operating Voltage DC (V) 5 – 12 Input current (A) – Safety current (A) 0.5 Input power (W) 6 Rated Current LED (A) – Accessories 3-pin to 4-pin 12V-connector – 12V to 7V adapter – 12V to 5V adapter – Screws 4 Push pins – hard plastic washer – Others –
