Lenovo Legion 5 Pro 16IRX9 83DF00KFED PERFORMANCE Processor Intel® Core™ i7-14650HX, 16C (8P 8E) / 24T, P-core 2.2 / 5.2GHz, E-core 1.6 / 3.7GHz, 30MB AI PC Category AI-Powered Gaming PC Graphics NVIDIA® GeForce RTX™ 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 140W, 233 AI TOPS Chipset Intel® HM770 Chipset Memory 1x 16GB SO-DIMM DDR5-5600 Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable Max Memory Up to 32GB DDR5-5600 offering Storage 1TB SSD M.2 2280 PCIe® 4.0×4 NVMe® Storage Support Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB Storage Slot Two M.2 2280 PCIe® 4.0 x4 slots Card Reader None Optical None Audio Chip High Definition (HD) Audio, Realtek® ALC3287 codec Speakers Stereo speakers, 2W x2, optimized with Nahimic Audio Camera FHD 1080p with Privacy Shutter Microphone 2x, Array Battery 80Wh Power Adapter 300W Slim Tip (3-pin) Special Features AI Chip: LA1 DESIGN Display 16″ WQXGA (2560×1600) IPS 500nits Anti-glare, 100% DCI-P3, 240Hz, DisplayHDR™ 400, Dolby Vision®, G-SYNC®, Low Blue Light, High Gaming Performance Touchscreen None Color Calibration Factory Color Calibration Keyboard 4-Zone RGB Backlit, Arabic Touchpad Buttonless Mylar® surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches) Case Color Onyx Grey Surface Treatment Anodizing Case Material Aluminium (Top), PC-ABS (Bottom) Pen Pen Not Supported Dimensions (WxDxH) 363.4 x 261.75 x 21.99-26.95 mm (14.31 x 10.31 x 0.87-1.06 inches) Weight Around 2.5 kg (5.5 lbs) SOFTWARE Operating System None Bundled Software None CONNECTIVITY WLAN Bluetooth Wi-Fi® 6E, 802.11ax 2×2 BT5.2 WWAN Non-WWAN Ethernet 100/1000M (RJ-45) Standard Ports 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On 3x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with Lenovo® PD 140W and DisplayPort™ 1.4 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort™ 1.4 1x HDMI® 2.1, up to 8K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (RJ-45) 1x Power connector Docking Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for Legion Pro 5 16IRX9 SECURITY & PRIVACY Security Chip Firmware TPM 2.0 Enabled Fingerprint Reader None Other Security E-shutter SERVICE Base Warranty 1-year, Courier or Carry-in Included Upgrade 2Y Courier/Carry-in upgrade from 1Y Courier/Carry-in ACCESSORIES Bundled Accessories Lenovo® Legion™ Gaming Speed Mouse Pad M CERTIFICATIONS Green Certifications ErP Lot 3 RoHS compliant Other Certifications TÜV Rheinland® High Gaming Performance TÜV Rheinland® Low Blue Light (Hardware Solution)
