Characteristics Switch, Fixed Port type Total number of ports 24 Main ports, type 24×10/100/1000Base-T Power Over Ethernet (PoE) 12x 802.3at PoE ports, 130W Total PoE budget Uplink Ports – Free (10GB) slots No Management Built-in Web-based browser for simple configuration and management; Network Management: SNMP v1, v2, v3; RMON (1, 2, 3, 9); ICMP echo/echo reply; Syslog; IEEE 802.1AB LLDP; IEEE 802.1AB LLDP-MED Stackable no Fans Fanless design Power supply Input voltage of AC: 100 – 240 V AC, 50/60 Hz; Max. power consumption: 166.5 W Routing Layer 2 Only Memory (Flash, RAM) Packet Buffer: 525 KB Routing/switching capacity, Gbps 48 Gbps Bandwidth, Mpps 35.7 Mpps MAC addresses 8000 MAC address table size VLAN (number, standards) Port-based VLAN, IEEE 802.1Q VLAN tagging, IEEE 802.3ad LACP, Guest VLAN, Voice VLAN QoS IEEE 802.1p priority queues per port, IEEE 802.1p Queuing method (scheduler), Input priority mapping, Rate limiting per port (ingress/egress) L2 network standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x flow control, IEEE 802.3az EEE support, IEEE 802.1p CoS support, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s L3 network standards – IPv6 functionality IPv6 over Ethernet, Dual-stack, ICMPv6, Neighbor discovery, Auto configuration, Static IPv6 address and prefix length, Static IPv6 default gateway, IPv6 duplicate address detection Security IEEE 802.1x, Port security, Layer 2 MAC filtering, Static MAC forwarding, RADIUS, TACACS , SSL, Management VLAN, CPU defense engine, DoS prevention Dimensions (W, L, H), mm 330 x 230 x 44 Rackmount option Warranty 99 months
